SPUN-COPPER THERMOFORMED CRYSTALLINE POLYMER (TCP) WOOFERS
Thermoformed Crystalline Polymer (TCP) woofers are exceptionally light while being extremely rigid and tightly packed – providing remarkable low frequency response, with minimal cone breakup and distortion without degradation.
ALL-DIGITAL AMPLIFIER
The built-in, all-digital amplifier delivers ample power with high efficiency and true-to-source accuracy in reproduction, ensuring maximum efficiency for maximum output, detail, and power.
FRONT-FIRING DRIVER
The high-performance driver provides deep bass and room placement flexibility.
LOW PASS CROSSOVER AND PHASE CONTROL
Ensures the subwoofer’s low-frequency tones blend with other Klipsch speakers and establish the ideal level of bass for your room.
LINE/LFE INPUTS
Ensures compatibility with home theater receivers.
MDF CABINET WITH SCRATCH-RESISTANT, TEXTURED WOOD GRAIN VINYL
Stylish aesthetic with absolute durability that results in a seamless integration into any décor.
HIGH QUALITY CABINET DESIGN
Reinforced 3/4” MDF construction with an all-new bracing design reduces cabinet vibration for less audible coloration and improved sonic accuracy.
FRONT-MOUNTED LED POWER INDICATOR
Indicates when the system is on or off.
LOW PROFILE GRILLE
Adds a refined look that is acoustically transparent.
| Specifications | |
|---|---|
| WIDTH INCHES (MM) | 14.0" (356 mm) |
| HEIGHT INCHES (MM) | 14.6" (370 mm) |
| INPUTS | Line level/LFE RCA jacks |
| ENCLOSURE TYPE | Bass-Reflex via rear-firing port |
| ENCLOSURE MATERIAL | MDF |
| DRIVER COMPONENTS | 10" high excursion spun-copper TCP woofer |
| FREQUENCY RANGE | 29.5Hz - 120Hz |
| MAXIMUM ACOUSTIC OUTPUT | 115 dB |
| AMPLIFIER | All Digital |
| AMPLIFIER FEATURES | Volume, Low-pass, 0/180 phase, Auto Power On |
| AMPLIFIER POWER (CONT/PEAK) | 150W/300W |
| DEPTH INCHES (MM) | 19.7" (500 mm) |
| PRODUCT WEIGHT LBS (KG) | 31 lbs (13.9 kg) |
| FINISHES | Black Textured Wood Grain Vinyl |
